Corner Radius (Decimal)
0.0000
Cutting Width (Metric)
0.43
ANSI Designation
GBF32R043000FGW15
Corner Radius (Metric)
0.00
Cutting Width (Decimal)
0.0169
ISO Designation
GBF32R043-000F
Insert Holding Method
Screw
Insert Thickness (Fractional)
1/8
Number of Cutting Edges
3
Cutting Range
Medium-Roughing
Usage Classification
Continuous to Light Interruption
Cutting Width Minimum (Decimal)
0.0169
Cutting Width Minimum (Metric)
0.43
Cutting Width Maximum (Decimal)
0.0169
Cutting Width Maximum (Metric)
0.43
Maximum Depth of Cut (Decimal)
0.0394
Maximum Depth of Cut (Metric)
1.00
Insert Thickness (Metric)
3.18
PDF 1
https://s3-us-west-2.amazonaws.com/catsy.739/GBF_Grooving_for_Small_Parts.pdf
PDF 2
https://s3-us-west-2.amazonaws.com/catsy.739/Small_Part_Tooling_Solutions.pdf
PDF 3
https://s3-us-west-2.amazonaws.com/catsy.739/JCTM-Series.pdf
Machining Operations
External Grooving
Workpiece Material
Cast Iron, Non-Ferrous, High-Temp Alloy
