Primary Workpiece Material
(H) Hardened Materials
Corner Radius (Metric)
0.40
Corner Radius (Fractional)
1/64
Cutting Width (Decimal)
0.24
Application
External Grooving
Insert Holding Method
Clamp
Insert Length (Decimal)
0.79
Insert Length (Metric)
20
Old Material Number
8837407
ANSI Part Number
GDGS6020N040NBKBN05M
ISO Part Number
GDGS6020N-040NB
Number of Cutting Edges
1
Usage Classification
Continuous
Cutting Width Minimum (Decimal)
0.24
Cutting Width Minimum (Metric)
6
Cutting Width Maximum (Decimal)
0.24
Cutting Width Maximum (Metric)
6
Max Depth of Cut (Decimal)
1.18
Max Depth of Cut (Metric)
30
PDF 1
https://s3-us-west-2.amazonaws.com/catsy.739/KGD_KGDF_Grooving_and_Cut-Off.pdf
PDF 2
https://s3-us-west-2.amazonaws.com/catsy.739/Automotive_Tooling_Solutions.pdf
PDF 3
https://s3-us-west-2.amazonaws.com/catsy.739/JCT-Series_Coolant-Through_Holders.pdf
