Kyocera Grooving Insert GER140005D PR1225: TKE17066
SKU: KYP-TKE17066
Kyocera Grooving Insert GER230020DM PR1225, manufacturer part number TKE17116.
Specifications: Insert Thickness: 5.05 mm (0.1990 in); Corner Radius: 0.20 mm (0.0080 in); Cutting Width: 2.30 mm (0.0906 in); Insert Holding Method: Screw; Insert Length: 16.44 mm (0.6472 in); Old Material Number: 8836835; Rake: Positive; Number of Cutting Edges: 2; Cutting Range: Medium-Roughing; Full Radius: No; Usage Classification: Continuous; Cutting Width Minimum: 2.30 mm (0.0906 in); Cutting Width Maximum: 2.30 mm (0.0906 in); Maximum Depth of Cut: 3.20 mm (0.1260 in); Insert Shape: Irregular; Insert Size: 230020; Insert Style: GE; Hand Direction: Right; ANSI Designation: GER230020DMPR1225; Chip Breaker Type: M; ISO Designation: GER230-020DM; Machining Operations: Internal Grooving; Insert Grade: PR1225; Workpiece Material: Steel, Stainless Steel; Coating Process: PVD.
Material: Carbide. Coating/Finish: MEGACOAT. Series: SIGE. Unit of measure: Metric.
