Shank Type
Standard Length
Cutting Diameter (Decimal)
2.4803 - 2.9921
Cutting Diameter (Metric)
63 - 76
Application
Chamfering, Facing
Insert Holding Method
Screw
Old Material Number
8835298
ANSI Part Number
MFPN45063RS324T
ISO Part Number
MFPN45063R-S32-4T
Material Group / Grade
GR99
Cutting Diameter Minimum (Decimal)
2.48
Maximum Depth of Cut (Decimal)
0.24(GM/SM/GH), 0.20 (GL), 0.12 (W)
Maximum Depth of Cut (Metric)
6 (GM/SM/GH), 5 (GL), 3 (W)
Cutting Diameter Minimum (Metric)
63
Cutting Maximum (Decimal)
2.99
Connection Diameter (Decimal)
1.26
Connection Diameter (Metric)
32
Tool Entering Angle
45 degrees
PDF 1
https://s3-us-west-2.amazonaws.com/catsy.739/MFPN_High_Efficiency_Milling_Cutter.pdf
