Cutting Diameter (Decimal)
3 - 3.32
Cutting Diameter (Metric)
76.20 - 84.20
Cutting Diameter
3.32 Inch
Application
Chamfering, Facing
Insert Holding Method
Screw
Old Material Number
8606118
ANSI Part Number
MFPN453000R8T
ISO Part Number
MFPN453000R-8T
Material Group / Grade
GR99
Cutting Diameter Minimum (Decimal)
3
Max. Depth Of Cut
0.24 Inch
Maximum Depth of Cut (Decimal)
0.24(GM/SM/GH), 0.20 (GL), 0.12 (W)
Maximum Depth of Cut (Metric)
6 (GM/SM/GH), 5 (GL), 3 (W)
Cutting Diameter Minimum (Metric)
76.20
Cutting Maximum (Metric)
84.20
Connection Bore Diameter (Decimal)
1
Connection Bore Diameter (Metric)
25.40
Contact Surface Diameter Machine Side (Decimal)
2.28
Contact Surface Diameter Machine Side (Metric)
58
Tool Entering Angle
45 degrees
Cutter Pitch
Extra-Fine Pitch
