Cutting Diameter (Decimal)
400 - 4.3150
Cutting Diameter (Metric)
101.60 - 109.60
Cutting Diameter
4.32 Inch
Application
Chamfering, Facing
Insert Holding Method
Screw
Old Material Number
8605961
ANSI Part Number
MFPN454000R6T
ISO Part Number
MFPN454000R-6T
Material Group / Grade
GR99
Cutting Diameter Minimum (Decimal)
4
Max. Depth Of Cut
0.24 Inch
Maximum Depth of Cut (Decimal)
0.24(GM/SM/GH), 0.20 (GL), 0.12 (W)
Maximum Depth of Cut (Metric)
6 (GM/SM/GH), 5 (GL), 3 (W)
Cutting Diameter Minimum (Metric)
101.60
Cutting Maximum (Metric)
109.60
Connection Bore Diameter (Decimal)
1.50
Connection Bore Diameter (Metric)
38.10
Contact Surface Diameter Machine Side (Decimal)
2.76
Contact Surface Diameter Machine Side (Metric)
70
Tool Entering Angle
45 degrees
Cutter Pitch
Coarse Pitch
