Kyocera SDKW 09T204TN PR1825 Grade PVD Carbide, Indexable Milling Insert

Kyocera Precision Tools

No reviews yet Write a Review
SKU:
KYP-TLT00025
$29.35
Kyocera SDKW 09T204TN PR1825 Grade PVD Carbide, 90 Degree Square, Positive Rake Angle, Neutral Milling Insert for Roughing in (P) Carbon/Alloy Steel, (P) Mold Steel and (M) Austenitic Stainless Steel

Specifications

Series
MCSE
Unit of Measure
Metric
Cutting Direction
Neutral
Material
Carbide
Coating/Finish
PVD
Primary Workpiece Material
(P) Carbon/Alloy Steel|(P) Mold Steel
Corner Radius
0.40 mm
Corner Radius (Fractional)
1/64
Grade
PR1825
Inscribed Circle (Metric)
9.53
Thickness
2.78 mm
Style
SDKW
Application
Back Chamfering, Chamfering, Countersinking, V-Shape Slotting
Thickness (Decimal)
0.11
Shape
90 Degree Square
Insert Holding Method
Screw
ANSI Part Number
SDKW09T204TNPR1825
ISO Part Number
SDKW09T204TN
Rake
Positive
Number of Cutting Edges
4
Insert Size
09T204
Chipbreaker
TN
Cutting Range
Roughing
Inscribed Circle (Fractional)
3/8
Insert Included Angle (Degree)
90 degrees
Pack quantity
10
PDF 3
https://s3-us-west-2.amazonaws.com/catsy.739/PR18-Series_Milling_Grades.pdf
Kyocera SDKW 09T204TN PR1825 Grade PVD Carbide, Indexable Milling Insert
$29.35
Add to Your List
Request a Quote

Buying in volume or need custom terms? Request a Quote.
