Kyocera SDMT 3181C KW10 Grade Uncoated Carbide, Indexable Milling Insert

Kyocera Precision Tools

No reviews yet Write a Review
SKU:
KYP-TWE00797
$25.71
Kyocera SDMT 3181C KW10 Grade Uncoated Carbide, Square, Positive Rake Angle, Neutral Milling Insert for Roughing in (N) Non-Ferrous Metals and (K) Gray Cast Iron, (K) Nodular Cast Iron

Specifications

Series
MCSE
Unit of Measure
Metric
Cutting Direction
Neutral
Material
Carbide
Coating/Finish
Uncoated
Primary Workpiece Material
(N) Non-Ferrous Materials
Corner Radius
0.40 mm
Corner Radius (Fractional)
1/64
Grade
KW10
Inscribed Circle (Metric)
9.53
Thickness
2.78 mm
Style
SDMT
Application
Back Chamfering, Chamfering, Countersinking, V-Shape Slotting
Thickness (Decimal)
0.11
Shape
90 Degree Square
Insert Holding Method
Screw
Old Material Number
8813446
ANSI Part Number
SDMT3181CKW10
ISO Part Number
SDMT09T204C
Rake
Positive
Number of Cutting Edges
4
Insert Size
3181
Chipbreaker
C
Cutting Range
Roughing
Inscribed Circle (Fractional)
3/8
Insert Included Angle (Degree)
90 degrees
Pack quantity
10
Kyocera SDMT 3181C KW10 Grade Uncoated Carbide, Indexable Milling Insert
$25.71
