Kyocera Turning Insert SNMG432C CA320: TME05165

Kyocera Precision Tools

No reviews yet Write a Review
SKU:
KYP-TME05165
$18.77

Kyocera Turning Insert SNMG432C CA320, manufacturer part number TME05165.

Specifications: IC Size: 1/2 in (12.70 mm); Insert Thickness: 3/16 in (4.76 mm); Corner Radius: 1/32 in (0.80 mm); Insert Holding Method: Screw or Clamp; Old Material Number: 8848544; Rake: Negative; Number of Cutting Edges: 8; Cutting Range: Roughing; Usage Classification: Continuous to Heavy Interruption; Insert Size: 432; Hand Direction: Neutral; Insert Style: SNMG; ANSI Designation: SNMG432CCA320; Chip Breaker Type: C; ISO Designation: SNMG120408C; Included Angle: 90 degrees; Machining Operations: Boring, Chamfering, External Turning, Facing; Insert Grade: CA320; Workpiece Material: Cast Iron; Insert Shape: Square; Coating Process: CVD.

Material: Carbide. Coating/Finish: TiCN/Al2O3/Ti. Series: ISOI. Unit of measure: Inch.

Specifications

Series
ISOI
Unit of Measure
Inch
Hand Direction
Neutral
Material
Carbide
Coating/Finish
TiCN/Al2O3/Ti
Insert Thickness (Fractional)
3/16
Corner Radius (Fractional)
1/32
Included Angle
90
ANSI Designation
SNMG432CCA320
Insert Style
SNMG
Insert Thickness (Metric)
4.76
Insert Shape
Square
Insert Holding Method
Screw or Clamp
Insert Size
432
Old Material Number
8848544
Machining Operations
Boring, Chamfering, External Turning, Facing
Insert Grade
CA320
Rake
Negative
IC Size (Metric)
12.70
Corner Radius (Metric)
0.80
Number of Cutting Edges
8
Workpiece Material
Cast Iron
ISO Designation
SNMG120408C
Cutting Range
Roughing
Usage Classification
Continuous to Heavy Interruption
IC Size (Fractional)
1/2
Coating Process
CVD
Chip Breaker Type
C
Pack quantity
10
