Kyocera Turning Insert SNMM644PX CA025P: TMH00251

Kyocera Precision Tools

No reviews yet Write a Review
SKU:
KYP-TMH00251
$46.88

Kyocera Turning Insert SNMM644PX CA025P, manufacturer part number TMH00251.

Specifications: IC Size: 3/4 in (19.05 mm); Insert Thickness: 1/4 in (6.35 mm); Corner Radius: 1/16 in (1.60 mm); Insert Holding Method: Screw or Clamp; Old Material Number: 8860499; Rake: Negative; Number of Cutting Edges: 4; Cutting Range: Roughing; Usage Classification: Continuous to Light Interruption; Insert Size: 644; Hand Direction: Neutral; Insert Style: SNMM; ANSI Designation: SNMM644PXCA025P; Chip Breaker Type: PX; ISO Designation: SNMM190616PX; Included Angle: 90 degrees; Machining Operations: Boring, Chamfering, External Turning, Facing; Insert Grade: CA025P; Workpiece Material: Steel; Insert Shape: Square; Coating Process: CVD.

Material: Carbide. Coating/Finish: TiCN/Al2O3/TiN. Series: ISOI. Unit of measure: Inch.

Specifications

Series
ISOI
Unit of Measure
Inch
Hand Direction
Neutral
Material
Carbide
Coating/Finish
TiCN/Al2O3/TiN
Insert Thickness (Fractional)
1/4
Corner Radius (Fractional)
1/16
Included Angle
90
ANSI Designation
SNMM644PXCA025P
Insert Style
SNMM
Insert Thickness (Metric)
6.35
Insert Shape
Square
Insert Holding Method
Screw or Clamp
Insert Size
644
Old Material Number
8860499
Machining Operations
Boring, Chamfering, External Turning, Facing
Insert Grade
CA025P
Rake
Negative
IC Size (Metric)
19.05
Corner Radius (Metric)
1.60
Number of Cutting Edges
4
Workpiece Material
Steel
ISO Designation
SNMM190616PX
Cutting Range
Roughing
Usage Classification
Continuous to Light Interruption
IC Size (Fractional)
3/4
Coating Process
CVD
Chip Breaker Type
PX
Pack quantity
10
