Kyocera TEEN 32PTFR KPD010 Grade PCD, Indexable Milling Insert

Kyocera Precision Tools

No reviews yet Write a Review
SKU:
KYP-TBE00260
$322.04
Kyocera TEEN 32PTFR KPD010 Grade PCD, Triangle, Positive Rake Angle, Right-Hand Milling Insert for Finishing in (N) Non-Ferrous Metals, (S) Titanium Alloy

Specifications

Series
MTES
Unit of Measure
Metric
Cutting Direction
Right
Material
PCD
Coating/Finish
Uncoated
Primary Workpiece Material
(N) Non-Ferrous Materials|(S) Titanium Alloy
Grade
KPD010
Inscribed Circle (Metric)
9.53
Thickness
3.18 mm
Style
TEEN
Application
Facing, Shouldering, Slotting
Thickness (Fractional)
1/8
Shape
60 Degree Triangle
Insert Holding Method
Clamp
Old Material Number
8814099
ANSI Part Number
TEEN32PTFRKPD010
ISO Part Number
TEEN1603PTFR
Rake
Positive
Number of Cutting Edges
1
Insert Size
32
Chipbreaker
PTFR
Cutting Range
Finishing
Inscribed Circle (Fractional)
3/8
Insert Included Angle (Degree)
60 degrees
Kyocera TEEN 32PTFR KPD010 Grade PCD, Indexable Milling Insert
$322.04
Add to Your List
Request a Quote

Buying in volume or need custom terms? Request a Quote.
