Kyocera TEKR 43PTERS PR1225 Grade PVD Carbide, Indexable Milling Insert

Kyocera Precision Tools

No reviews yet Write a Review
SKU:
KYP-TKB05826
$36.93
Kyocera TEKR 43PTERS PR1225 Grade PVD Carbide, Triangle, Positive Rake Angle, Right-Hand Milling Insert for Roughing in (P) Free-Cutting Steel, (P) Carbon/Alloy Steel, (P) Mold Steel, (M) Stainless Steel

Specifications

Series
MTE
Unit of Measure
Metric
Cutting Direction
Right
Material
Carbide
Coating/Finish
PVD
Primary Workpiece Material
(P) Free-Cutting Steel|(P) Carbon/Alloy Steel|(P) Mold Steel|(M) Stainless Steel
Corner Radius
1 mm
Grade
PR1225
Inscribed Circle (Metric)
12.70
Thickness
4.76 mm
Style
TEKR
Application
Facing, Shouldering, Slotting
Thickness (Fractional)
3/16
Shape
60 Degree Triangle
Insert Holding Method
Clamp
Old Material Number
8833973
ANSI Part Number
TEKR43PTERSPR1225
ISO Part Number
TEKR2204PTER-S
Rake
Positive
Number of Cutting Edges
3
Insert Size
43
Chipbreaker
PTERS
Cutting Range
Roughing
Corner Radius (Decimal)
0.04
Inscribed Circle (Fractional)
1/2
Insert Included Angle (Degree)
60 degrees
Pack quantity
10
Kyocera TEKR 43PTERS PR1225 Grade PVD Carbide, Indexable Milling Insert
$36.93
Add to Your List
Request a Quote

Buying in volume or need custom terms? Request a Quote.
