Kyocera Turning Insert TPGT151505MPCF PR1225: TKE06716

Kyocera Turning Insert TPGT151505MPCF PR1225, manufacturer part number TKE06716.

Specifications: IC Size: 3/16 in (4.76 mm); Insert Thickness: 3/32 in (2.38 mm); Corner Radius: 0.0080 in (0.20 mm); Insert Holding Method: Screw or Clamp; Old Material Number: 8831972; Rake: Positive; Number of Cutting Edges: 3; Cutting Range: Finishing; Usage Classification: Continuous to Light Interruption; Insert Size: 151505; Hand Direction: Neutral; Insert Style: TPGT; ANSI Designation: TPGT151505MPCFPR1225; Chip Breaker Type: CF; ISO Designation: TPGT080202MP-CF; Included Angle: 60 degrees; Machining Operations: Back Boring, Boring, Copying, External Turning, Internal Facing; Insert Grade: PR1225; Workpiece Material: Stainless Steel, Steel; Insert Shape: Triangle; Coating Process: PVD.

Material: Carbide. Coating/Finish: MEGACOAT. Series: ISOI. Unit of measure: Inch.
