Kyocera Turning Insert VCMT151505HQ PV710: TLF07650

Kyocera Turning Insert VCMT151505HQ PV710, manufacturer part number TLF07650.

Specifications: IC Size: 3/16 in (4.76 mm); Insert Thickness: 3/32 in (2.38 mm); Corner Radius: 0.0080 in (0.20 mm); Insert Holding Method: Screw or Clamp; Old Material Number: 8847719; Rake: Positive; Number of Cutting Edges: 2; Cutting Range: Finishing-Medium; Usage Classification: Continuous; Insert Size: 151505; Hand Direction: Neutral; Insert Style: VCMT; Insert Shape: 35 Degree Diamond; ANSI Designation: VCMT151505HQPV710; Chip Breaker Type: HQ; ISO Designation: VCMT080202HQ; Included Angle: 35 degrees; Machining Operations: Back Boring, Copying, External Turning, Facing, Internal Facing, Profiling, Undercutting; Insert Grade: PV710; Workpiece Material: Steel; Coating Process: PVD.

Material: Cermet. Coating/Finish: TiCN (MEGACOAT NANO). Series: ISOI. Unit of measure: Inch.
