Unit of Measure
Fractional
Cutting Diameter (Decimal)
0.25
Cutting Diameter (Metric)
6.35
Shank Diameter (Decimal)
0.25
Shank Diameter (Metric)
6.35
Shank Diameter (Fractional)
1/4
Overall Length (Decimal)
2
Overall Length (Metric)
50.80
Primary Workpiece Material
"(P) Steel, (M) Stainless Steel, (K) Cast Iron, (N) Non-Ferrous Materials, (S) High Temp Alloy"
Secondary Workpiece Material
(H) Hardened Materials
Cutting Diameter Tolerance (Decimal)
+.00000 / -.00050
Cutting Diameter Tolerance (Metric)
+.0000 / -.0127
Shank Diameter Tolerance (ISO)
h6
Coolant Option
External Coolant
Coating Description
Uncoated
Additional Geometry
Right Hand Cut Direction (RHC)
Max. Cutting Diameter
1/4 Inch
Tip Diameter (Decimal)
0.05
Tip Diameter (Metric)
1.27
Flute Length (Decimal)
0.38
Flute Length (Metric)
9.53
Flute Length (Fractional)
3/8
Shank Length (Decimal)
1.25
Shank Length (Metric)
31.75
