Unit of Measure
Fractional
Cutting Diameter (Decimal)
1
Cutting Diameter (Metric)
25.40
Shank Diameter (Decimal)
0.50
Shank Diameter (Metric)
12.70
Shank Diameter (Fractional)
1/2
Overall Length (Decimal)
3
Overall Length (Metric)
76.20
Primary Workpiece Material
"(P) Steel, (M) Stainless Steel, (K) Cast Iron, (N) Non-Ferrous Materials, (S) High Temp Alloy"
Secondary Workpiece Material
(H) Hardened Materials
Cutting Diameter Tolerance (Decimal)
+.00300 / -.00000
Cutting Diameter Tolerance (Metric)
+.0762 / -.0000
Shank Diameter Tolerance (ISO)
h6
Coolant Option
External Coolant
Coating Description
Uncoated
Additional Geometry
Right Hand Cut Direction (RHC)
Max. Cutting Diameter
1 Inch
Tip Diameter (Decimal)
0.24
Tip Diameter (Metric)
6.10
Flute Length (Decimal)
0.38
Flute Length (Metric)
9.53
Flute Length (Fractional)
3/8
Shank Length (Decimal)
1.75
Shank Length (Metric)
44.45
