SGS Square End Mill: 10.00mm Dia, 22.00mm LOC, 75.00mm OAL, 5 Flute, AlTiN, 10.00mm Shank, 42613

Kyocera SGS

No reviews yet Write a Review
SKU:
KYO-42613
$142.75

Cut slots, shoulders, pockets and profiles with this 10.00mm 5-flute solid carbide square end mill.

SGS Series 55M square end mills are made for steel, stainless steel, cast iron and high-temp alloys.

  • Cutting diameter: 10.00mm
  • Length of cut: 22.00mm
  • Overall length: 75.00mm
  • Shank diameter: 10.00mm
  • Number of flutes: 5
  • Coating/finish: AlTiN
  • Material: Solid Carbide
  • Workpiece material: Steel, Stainless Steel, Cast Iron, High-Temp Alloy

SGS part number 42613.

Specifications

Series
55M
Unit of Measure
Metric
Shank Diameter (Metric)
10.00
Length of Cut (Metric)
22.00
Overall Length (Metric)
75.00
Number of Flutes
5
Shank Type
Weldon Flat
Shank Length (Decimal)
2.0866
Hand Direction
Right
Material
Solid Carbide
Coating/Finish
AlTiN
Cutting Diameter (Decimal)
0.3937
Length of Cut (Decimal)
0.8661
Shank Diameter (Decimal)
0.3937
Overall Length (Decimal)
2.9528
Flute Type
Spiral
Helix Angle
45 degrees
Size System
Metric
Cutting Diameter (Metric)
10.00
Secondary Workpiece Material
Hardened Steel
Cutting Diameter Tolerance (Decimal)
+0.0000/-0.0020
Cutting Diameter Tolerance (Metric)
+0.000/-0.050
End Type
Square
Coolant Option
External Coolant
Shank Length (Metric)
53.00
Performance Class
High Performance
Rake
Positive
DIN Standard (Shank)
DIN 6535 HB
Shank Tolerance
h6
Workpiece Material
Steel, Stainless Steel, Cast Iron, High-Temp Alloy
Variable Helix
No
Center Cutting
Yes
Chip Breaker
No
Helix Direction
Right
Length Type
Standard
Maximum Workpiece Hardness
45 HRC
