Unit of Measure
Fractional
Cutting Diameter (Decimal)
0.54
Cutting Diameter (Metric)
13.49
Shank Diameter (Decimal)
0.63
Shank Diameter (Metric)
15.88
Overall Length (Decimal)
4.88
Overall Length (Metric)
123.83
Primary Workpiece Material
"(P) Steel, (M) Stainless Steel, (H) Hardened Materials"
Secondary Workpiece Material
(K) Cast Iron|(N) Non-Ferrous Materials|(S) High Temp Alloy
Cutting Diameter Tolerance (Decimal)
+.00028 / +.00098
Cutting Diameter Tolerance (Metric)
+.0071 / +.0251
Shank Diameter Tolerance (ISO)
h6
Coolant Option
External Coolant
Coating Description
Ti-NAMITE-A (AlTiN)
Additional Geometry
Right Hand Cut Direction (RHC)
Flute Length (Decimal)
3.04
Flute Length (Metric)
76.99
Usable Length (Decimal)
2.60
Usable Length (Metric)
65.88
Usable Length (Fractional)
2-19/32
