SGS 20.00mm Dia, 2 Flute, Ball Nose End Mill - 44607

Kyocera SGS

No reviews yet Write a Review
SKU:
KYO-44607
$845.05
SGS 20.00mm Dia, 37.32mm LOC, 20.00mm Shank Dia, 2 Flute, 35 Degree Helix, Ti-NAMITE-B (TIB2) Coated, Series 47MB, S-Carb, Ball Nose End Mill - 44607

Specifications

Series
47MB
Unit of Measure
Metric
Length of Cut
37.32 mm
Shank Size
20 mm
Number Of Flutes
2
Shank Type
Straight
Overall Length
104 mm
Cutting Direction
Right
Material
Solid Carbide
Coating/Finish
Ti-NAMITE-B (TIB2)
Cutting Diameter (Decimal)
0.79
Length of Cut (Decimal)
1.47
Shank Diameter (Decimal)
0.79
Overall Length (Decimal)
4.10
Flute Type
Spiral
Helix Angle
35 degrees
Primary Workpiece Material
(N) Non-Ferrous Materials
Secondary Workpiece Material
Plastics & Composites
Cutting Diameter Tolerance (Decimal)
+0.0000/-0.00051
Cutting Diameter Tolerance (Metric)
+0.000/-0.013
Shank Diameter Tolerance (ISO)
h6
Corner Radius Tolerance (Decimal)
+0.0005/-0.0005
Corner Radius Tolerance (Metric)
+0.013/-0.013
Coolant Option
External Coolant
Additional Geometry
Right Hand Cut Direction (RHC)
Rake Angle
Positive
High Performance
Yes
Weldon Flat
No
Variable Helix
No
Center Cutting
Yes
Type
S-Carb
Cutting Diameter
20 mm
SGS 20.00mm Dia, 2 Flute, Ball Nose End Mill - 44607
$845.05
Add to Your List
Request a Quote

Buying in volume or need custom terms? Request a Quote.
