SGS Square End Mill: 25.00mm Dia, 43.00mm LOC, 108.00mm OAL, 4 Flute, TiB2, Solid Carbide, 45013

Kyocera SGS

No reviews yet Write a Review
SKU:
KYO-45013
$1,241.45

SGS APR4 square end mill for non-ferrous metals, 4 flutes, variable helix, spiral flutes, center cutting, straight shank, internal coolant. Solid carbide, TiB2 coating. Manufacturer part number 45013.

Specifications

Series
APR4
Unit of Measure
Metric
Cutting Diameter (Metric)
25.00
Shank Diameter (Metric)
25.00
Length of Cut (Metric)
43.00
Number of Flutes
4
Shank Type
Straight
Overall Length (Metric)
108.00
Hand Direction
Right
Material
Solid Carbide
Coating/Finish
TiB2
Cutting Diameter (Decimal)
0.9843
Length of Cut (Decimal)
1.6929
Shank Diameter (Decimal)
0.9843
Overall Length (Decimal)
4.2520
Flute Type
Spiral
Helix Angle
38/41 degrees
Helix Direction
Right
End Type
Square
Cutting Diameter Tolerance (Decimal)
-0.0004/-0.0040
Cutting Diameter Tolerance (Metric)
-0.010/-0.100
Performance Class
High Performance
Coolant Option
Internal Coolant
Size System
Metric
Rake
Positive
Shank Tolerance
h6
Length Type
Stub
Workpiece Material
Non-Ferrous
Variable Helix
Yes
Center Cutting
Yes
Chip Breaker
Yes
Maximum Workpiece Hardness
150 HB
SGS Square End Mill: 25.00mm Dia, 43.00mm LOC, 108.00mm OAL, 4 Flute, TiB2, Solid Carbide, 45013
$1,241.45
Add to Your List
Request a Quote

Buying in volume or need custom terms? Request a Quote.
