SGS Ball End Mill: 5/64" Dia, .187" LOC, 1-1/2" OAL, 4 Flute, AlTiN (Ti-NAMITE-A), Solid Carbide, 30035

Kyocera SGS

No reviews yet Write a Review
SKU:
KYO-30035
$51.40

SGS 01B ball end mill for steel, stainless steel, cast iron, non-ferrous metals and high-temp alloys, 4 flutes, 30 degree helix, spiral flutes, center cutting, straight shank, external coolant. Solid carbide, AlTiN coating. Manufacturer part number 30035.

Specifications

Series
01B
Unit of Measure
Inch
Shank Diameter (Fractional)
1/8
Number of Flutes
4
Shank Type
Straight
Overall Length (Fractional)
1-1/2
Hand Direction
Right
Material
Solid Carbide
Coating/Finish
AlTiN
Cutting Diameter (Decimal)
0.0781
Cutting Diameter (Metric)
1.98
Length of Cut (Decimal)
0.1870
Length of Cut (Metric)
4.75
Shank Diameter (Decimal)
0.1250
Shank Diameter (Metric)
3.18
Overall Length (Decimal)
1.5000
Overall Length (Metric)
38.10
Flute Type
Spiral
Helix Angle
30 degrees
Cutting Diameter (Fractional)
5/64
Secondary Workpiece Material
Hardened Steel
Cutting Diameter Tolerance (Decimal)
+0.0000/-0.0020
Cutting Diameter Tolerance (Metric)
+0.000/-0.050
Size System
Fractional
Corner Radius Tolerance (Decimal)
+0.0000/-0.0010
Corner Radius Tolerance (Metric)
+0.000/-0.025
Coolant Option
External Coolant
Helix Direction
Right
Chip Breaker
No
End Type
Ball
Performance Class
General Purpose
Variable Helix
No
Center Cutting
Yes
Shank Length (Decimal)
1.3130
Length Type
Standard
Rake
Positive
Shank Length (Metric)
33.35
Shank Tolerance
h6
Workpiece Material
Steel, Stainless Steel, Cast Iron, Non-Ferrous, High-Temp Alloy
SGS Ball End Mill: 5/64" Dia, .187" LOC, 1-1/2" OAL, 4 Flute, AlTiN (Ti-NAMITE-A), Solid Carbide, 30035
$51.40
