SGS #6 7/32" Dia, 118 Degree, 2 Flute, Countersink - 57022

Kyocera SGS

No reviews yet Write a Review
SKU:
KYO-57022
$311.57
SGS #6 7/32" Dia, 118 Degree, 2 Flute, 1/2" Body Dia, Ti-NAMITE-A (AlTiN) Coated, Series 301, General Application Drill and Countersink Combo - 57022

Specifications

Series
301
Unit of Measure
Fractional
Number Of Flutes
2
Shank Type
Straight
Overall Length
3 Inch
Cutting Direction
Right
Material
Solid Carbide
Coating/Finish
Ti-NAMITE-A (AlTiN)
Cutting Diameter (Decimal)
0.22
Cutting Diameter (Metric)
5.56
Overall Length (Decimal)
3
Overall Length (Metric)
76.20
Flute Type
Spiral
Primary Workpiece Material
"(P) Steel, (M) Stainless Steel, (K) Cast Iron, (N) Non-Ferrous Materials, (S) High Temp Alloy"
Secondary Workpiece Material
(H) Hardened Materials
Coolant Option
External Coolant
Coating Description
Ti-NAMITE-A (AlTiN)
Additional Geometry
Right Hand Cut Direction (RHC)
High Performance
No
Weldon Flat
No
Variable Helix
No
Center Cutting
No
Chip Breaker
No
Chamfer Angle (a)
30 degrees
Max. Cutting Diameter
7/32 Inch
Point Angle
118 degrees
Cutting Diameter (Wire)
#6
Body Diameter (Decimal)
0.50
Body Diameter (Metric)
12.70
Body Diameter (Fractional)
1/2
Flute Length (Decimal)
0.94
Flute Length (Metric)
23.83
Shank Length (Decimal)
1.13
Shank Length (Metric)
28.55
Number of Margins
2
SGS #6 7/32" Dia, 118 Degree, 2 Flute, Countersink - 57022
$311.57
Add to Your List
Request a Quote

Buying in volume or need custom terms? Request a Quote.
