Primary Workpiece Material
(N) Non-Ferrous Materials
Corner Radius (Metric)
0.30
Inscribed Circle (Metric)
12.70
Cutting Width (Decimal)
0.11
Application
External Grooving
Thickness (Fractional)
3/16
Insert Holding Method
Screw or Clamp
Old Material Number
8810756
ANSI Part Number
GBA43L280030KW10
ISO Part Number
GBA43L280-030
Number of Cutting Edges
3
Cutting Range
Finishing-Medium
Usage Classification
Light Interruption
Corner Radius (Decimal)
0.01
Cutting Width Minimum (Decimal)
0.11
Cutting Width Minimum (Metric)
2.80
Cutting Width Maximum (Decimal)
0.11
Cutting Width Maximum (Metric)
2.80
Max Depth of Cut (Decimal)
0.16
Max Depth of Cut (Metric)
4
Inscribed Circle (Fractional)
1/2
