Primary Workpiece Material
(N) Non-Ferrous Materials
Corner Radius (Metric)
0.40
Corner Radius (Fractional)
1/64
Inscribed Circle (Metric)
12.70
Cutting Width (Decimal)
0.17
Application
External Grooving
Thickness (Fractional)
3/16
Insert Holding Method
Screw or Clamp
Old Material Number
8810776
ANSI Part Number
GBA43L430040KW10
ISO Part Number
GBA43L430-040
Number of Cutting Edges
3
Cutting Range
Finishing-Medium
Usage Classification
Light Interruption
Cutting Width Minimum (Decimal)
0.17
Cutting Width Minimum (Metric)
4.30
Cutting Width Maximum (Decimal)
0.17
Cutting Width Maximum (Metric)
4.30
Max Depth of Cut (Decimal)
0.20
Max Depth of Cut (Metric)
5
Inscribed Circle (Fractional)
1/2
