Kyocera PKM 40N030PM GW15 Grade Uncoated Carbide, Indexable Cut-Off Insert

Kyocera Precision Tools

No reviews yet Write a Review
SKU:
KYP-TWG40003
$31.81
Kyocera PKM 40N030PM GW15 Grade Uncoated Carbide, 0.1570" Cutting Width, Neutral Cut-Off Insert for Light Interruption and Finishing-Medium in (N) Non-Ferrous Metals and (S) Heat-Resistant Alloy

Specifications

Series
KPK
Unit of Measure
Imperial
Cutting Direction
Neutral
Material
Carbide
Primary Workpiece Material
(K) Cast Iron|(N) Non-Ferrous Materials
Cutting Width
0.16 Inch
Application
Cut-Off
Insert Holding Method
Self-Clamp
Old Material Number
8865569
ANSI Part Number
PKM40N030PMGW15
ISO Part Number
PKM40N-030PM
Rake
Positive
Material Group / Grade
GW15
Tool Style
PKM
Cutting Width (Decimal)
0.16
Cutting Width (Metric)
4
Cutting Width Minimum (Decimal)
0.16
Cutting Width Minimum (Metric)
4
Cutting Width Maximum (Decimal)
0.16
Cutting Width Maximum (Metric)
4
Corner Radius (Metric)
0.30
Number of Cutting Edges
1
Insert Size
40
Corner Radius (Decimal)
0.01
Chipbreaker
PM
Coating Process
Uncoated
Cutting Range
Finishing-Medium
Full Radius
No
Usage Classification
Light Interruption
Pack quantity
10
PDF 1
https://s3-us-west-2.amazonaws.com/catsy.739/KPK-Series_Cut-Off_Solutions.pdf
Kyocera PKM 40N030PM GW15 Grade Uncoated Carbide, Indexable Cut-Off Insert
$31.81
