Kyocera Turning Insert TBGT12102L KW10: TWE00373

Kyocera Precision Tools

No reviews yet Write a Review
SKU:
KYP-TWE00373
$35.95

Kyocera Turning Insert TBGT12102L KW10, manufacturer part number TWE00373.

Specifications: IC Size: 5/32 in (3.97 mm); Insert Thickness: 1/16 in (1.59 mm); Corner Radius: 0.0040 in (0.10 mm); Insert Holding Method: Screw or Clamp; Old Material Number: 8813925; Rake: Positive; Number of Cutting Edges: 3; Cutting Range: Finishing; Usage Classification: Continuous to Light Interruption; Insert Size: 12102; Hand Direction: Left; Insert Style: TBGT; ANSI Designation: TBGT12102LKW10; ISO Designation: TBGT060101L; Included Angle: 60 degrees; Machining Operations: Back Boring, Boring, Copying, Internal Facing; Insert Grade: KW10; Workpiece Material: Non-Ferrous, High-Temp Alloy, Cast Iron; Insert Shape: Triangle.

Material: Carbide. Coating/Finish: Uncoated. Series: ISOI. Unit of measure: Inch.

Specifications

Series
ISOI
Unit of Measure
Inch
Hand Direction
Left
Material
Carbide
Coating/Finish
Uncoated
IC Size (Fractional)
5/32
Included Angle
60
Corner Radius (Decimal)
0.0040
Insert Style
TBGT
Insert Thickness (Fractional)
1/16
Insert Shape
Triangle
Insert Holding Method
Screw or Clamp
Insert Size
12102
Old Material Number
8813925
Insert Thickness (Metric)
1.59
Machining Operations
Back Boring, Boring, Copying, Internal Facing
Rake
Positive
IC Size (Metric)
3.97
Corner Radius (Metric)
0.10
Number of Cutting Edges
3
Insert Grade
KW10
Cutting Range
Finishing
Usage Classification
Continuous to Light Interruption
ISO Designation
TBGT060101L
Workpiece Material
Non-Ferrous, High-Temp Alloy, Cast Iron
ANSI Designation
TBGT12102LKW10
Pack quantity
10
Kyocera Turning Insert TBGT12102L KW10: TWE00373
$35.95
Add to Your List
Request a Quote

Buying in volume or need custom terms? Request a Quote.
