Kyocera TPK 32PDFR KW10 Grade Uncoated Carbide, Indexable Milling Insert

Kyocera Precision Tools

No reviews yet Write a Review
SKU:
KYP-TWE00820
$22.61
Kyocera TPK 32PDFR KW10 Grade Uncoated Carbide, Triangle, Positive Rake Angle, Right-Hand Milling Insert for Roughing in (N) Non-Ferrous Metals and (K) Gray Cast Iron, (S) Titanium Alloy

Specifications

Series
MTP
Unit of Measure
Metric
Cutting Direction
Right
Material
Carbide
Coating/Finish
Uncoated
Primary Workpiece Material
(N) Non-Ferrous Materials
Grade
KW10
Inscribed Circle (Metric)
9.53
Thickness
3.18 mm
Style
TPK
Application
Facing, Shouldering, Slotting
Thickness (Fractional)
1/8
Shape
60 Degree Triangle
Insert Holding Method
Clamp
Old Material Number
8803533
ANSI Part Number
TPK32PDFRKW10
ISO Part Number
TPKN1603PDFR
Rake
Positive
Number of Cutting Edges
3
Insert Size
32
Chipbreaker
PDFR
Cutting Range
Roughing
Inscribed Circle (Fractional)
3/8
Insert Included Angle (Degree)
60 degrees
Pack quantity
10
