Kyocera Turning Insert TPMH221 KPD010: TBE00861

Kyocera Precision Tools

No reviews yet Write a Review
SKU:
KYP-TBE00861
$199.55

Kyocera Turning Insert TPMH221 KPD010, manufacturer part number TBE00861.

Specifications: IC Size: 1/4 in (6.35 mm); Insert Thickness: 1/8 in (3.18 mm); Corner Radius: 1/64 in (0.40 mm); Insert Holding Method: Screw or Clamp; Old Material Number: 8809441; Rake: Positive; Number of Cutting Edges: 1; Cutting Range: Finishing-Medium; Usage Classification: Continuous; Insert Size: 221; Hand Direction: Neutral; Insert Style: TPMH; ANSI Designation: TPMH221KPD010; ISO Designation: TPMH110304; Included Angle: 60 degrees; Machining Operations: Back Boring, Boring, Copying, External Turning, Internal Facing; Insert Grade: KPD010; Workpiece Material: Non-Ferrous, High-Temp Alloy; Insert Shape: Triangle.

Material: PCD. Coating/Finish: Uncoated. Series: ISOI. Unit of measure: Inch.

Specifications

Series
ISOI
Unit of Measure
Inch
Hand Direction
Neutral
Material
PCD
Coating/Finish
Uncoated
IC Size (Metric)
6.35
Corner Radius (Fractional)
1/64
Included Angle
60
ANSI Designation
TPMH221KPD010
Insert Style
TPMH
Insert Thickness (Metric)
3.18
Insert Shape
Triangle
Insert Holding Method
Screw or Clamp
Insert Size
221
Old Material Number
8809441
Machining Operations
Back Boring, Boring, Copying, External Turning, Internal Facing
Insert Grade
KPD010
Rake
Positive
Insert Thickness (Fractional)
1/8
Corner Radius (Metric)
0.40
Number of Cutting Edges
1
Workpiece Material
Non-Ferrous, High-Temp Alloy
Cutting Range
Finishing-Medium
Usage Classification
Continuous
IC Size (Fractional)
1/4
ISO Designation
TPMH110304
