SGS 20.00mm Dia, 2 Flute, Ball Nose End Mill - 91361

Kyocera SGS

No reviews yet Write a Review
SKU:
KYO-91361
$1,739.38
SGS 20.00mm Dia, 20.00mm LOC, 41.25mm Reach, 20.00mm Shank Dia, 2 Flute, 30 Degree Helix, Ti-NAMITE-X (TX) Coated, Series 56B, Turbo-Carb, Ball Nose End Mill - 91361

Specifications

Series
56B
Unit of Measure
Metric
Length of Cut
20 mm
Shank Size
20 mm
Number Of Flutes
2
Shank Type
Straight
Overall Length
165 mm
Cutting Direction
Right
Material
Solid Carbide
Coating/Finish
Ti-NAMITE-X (TX)
Cutting Diameter (Decimal)
0.79
Length of Cut (Decimal)
0.79
Shank Diameter (Decimal)
0.79
Overall Length (Decimal)
6.50
Flute Type
Spiral
Helix Angle
30 degrees
Primary Workpiece Material
"(P) Steel, (K) Cast Iron, (H) Hardened Materials"
Reach (Decimal)
1.63
Reach (Metric)
41.25
Neck Diameter (Decimal)
0.78
Neck Diameter (Metric)
19.61
Cutting Diameter Tolerance (Decimal)
+0.0000/-0.0020
Cutting Diameter Tolerance (Metric)
+0.000/-0.050
Shank Diameter Tolerance (ISO)
h6
Corner Radius Tolerance (Decimal)
+0.0000/-0.0010
Corner Radius Tolerance (Metric)
+0.000/-0.025
Coolant Option
External Coolant
Additional Geometry
Right Hand Cut Direction (RHC)
Rake Angle
Positive
High Performance
Yes
Weldon Flat
No
Variable Helix
No
Center Cutting
Yes
Type
Turbo-Carb
Cutting Diameter
20 mm
SGS 20.00mm Dia, 2 Flute, Ball Nose End Mill - 91361
$1,739.38
Add to Your List
Request a Quote

Buying in volume or need custom terms? Request a Quote.
