Kyocera Turning Insert CCMW32505T00315ME KBN525: TBW01195

Kyocera Precision Tools

No reviews yet Write a Review
SKU:
KYP-TBW01195
$115.75

Kyocera ISOI turning insert for hardened steel, 3/8 in (9.525 mm) IC, 80 degree diamond shape, positive rake, 2 cutting edges, medium cutting range, screw or clamp insert holding, neutral hand. CBN, uncoated. Manufacturer part number TBW01195.

Specifications

Series
ISOI
Unit of Measure
Inch
Hand Direction
Neutral
Material
CBN
Coating/Finish
Uncoated
Insert Thickness (Metric)
3.97
Included Angle
80
Corner Radius (Decimal)
0.0080
Insert Style
CCMW
Machining Operations
Boring, External Turning, Facing, Internal Facing
Insert Shape
80 Degree Diamond
Insert Holding Method
Screw or Clamp
Insert Size
32505
IC Size (Metric)
9.525
Insert Grade
KBN525
Rake
Positive
Insert Thickness (Fractional)
5/32
Corner Radius (Metric)
0.20
Number of Cutting Edges
2
Workpiece Material
Hardened Steel
Cutting Range
Medium
Usage Classification
Continuous to Light Interruption
IC Size (Fractional)
3/8
ANSI Designation
CCMW32505T00315MEKBN525
ISO Designation
CCMW09T302T00815ME
